Bambu A1 · Fits the 256 mm bed

Print both broad side profiles flat as shown, 4 mm apart. PETG, 100% infill, 0.4 mm nozzle; no supports. The store reserves an 11 mm bed margin.

One pair per quantity. Soft lashing, loom and flat sticks are separate. Open seats do not lock the sticks. Support slack sticks for threading only; keep the cross tied independently and remove before tensioning or weaving. Physical print, fit and use tests are pending.

Custom lease-stick loom brackets

Name: Custom lease-stick loom brackets
Brand: 3DPrinterVerse

One PETG pair measured to a rectangular loom beam and flat lease sticks. Set stick positions, clearance and engagement; soft lashing and sticks separate.

Start with a preset

Measured example only. Check beam access, both stick ends and clearance to the shafts and warp.

Measure the beam, then the flat sticks

Measure a flat-topped rectangular beam front to back. The first stick center is measured from the beam face toward the shafts, before adding the printed wall. Measure both sticks lying flat: width front to back, thickness vertically. Clearances are total allowances, added once. Seat the beam against the inside-facing saddle leg before lashing so the first-center measurement starts at that contact face.

Finished beam opening:: 40.60 mm wide, 25.00 mm downward engagement. Check that both legs and lashing clear the loom.
Stick seats:: 20.60 mm wide, flat bottoms; 4.00 mm measured thickness with 3.00 mm of notch above it. Seats sit 5.00 mm above the beam top.
Stick positions:: 34.00 and 84.00 mm from the beam face, 50.00 mm center to center.
Space at each stick end:: Allow at least 18.00 mm outside the warp for the 14.00 mm wide bracket and a 4 mm yarn gap. Keep yarn off printed surfaces.
Complete pair print:: 143.70 × 78.00 × 14.00 mm, including a 4 mm print gap.

One PETG pair per quantity. Lash each saddle over its cap and around the beam using separate soft cord or straps. Open notches do not lock the sticks; keep the cross tied independently. For slack-stick support while threading; remove before tensioning, beaming or weaving. Flat sticks and rectangular beams only. Physical print, fit and use testing are pending.

Measured beam width front to back18–110 mm

Measured flat stick width8–38 mm

Measured flat stick thickness2–12 mm

Stick center spacing20–90 mm

First stick center from beam face12–90 mm

More dimensions (7)

Depth of beam engagement12–80 mm

Total beam width clearance0.3–2 mm

Total stick width clearance0.3–2 mm

Bracket width along beam10–28 mm

Mount and end wall thickness3.2–7 mm

Material below stick seats3.2–10 mm

Notch height above measured stick2–7 mm

Custom lease-stick loom brackets

One PETG pair measured to a rectangular loom beam and flat lease sticks. Set stick positions, clearance and engagement; soft lashing and sticks separate.

Start with a preset

Measured example only. Check beam access, both stick ends and clearance to the shafts and warp.

Measure the beam, then the flat sticks

Finished beam opening:: 40.60 mm wide, 25.00 mm downward engagement. Check that both legs and lashing clear the loom.
Stick seats:: 20.60 mm wide, flat bottoms; 4.00 mm measured thickness with 3.00 mm of notch above it. Seats sit 5.00 mm above the beam top.
Stick positions:: 34.00 and 84.00 mm from the beam face, 50.00 mm center to center.
Space at each stick end:: Allow at least 18.00 mm outside the warp for the 14.00 mm wide bracket and a 4 mm yarn gap. Keep yarn off printed surfaces.
Complete pair print:: 143.70 × 78.00 × 14.00 mm, including a 4 mm print gap.

Measured beam width front to back18–110 mm

Measured flat stick width8–38 mm

Measured flat stick thickness2–12 mm

Stick center spacing20–90 mm

First stick center from beam face12–90 mm

More dimensions (7)

Depth of beam engagement12–80 mm

Total beam width clearance0.3–2 mm

Total stick width clearance0.3–2 mm

Bracket width along beam10–28 mm

Mount and end wall thickness3.2–7 mm

Material below stick seats3.2–10 mm

Notch height above measured stick2–7 mm

Details

A pair of PETG brackets for holding flat lease sticks during threading of a slack warp. Fit the measured flat-topped rectangular loom beam, actual stick section and desired stick positions. Separate soft lashing is required around each bracket and beam; keep the cross tied independently. Loom, sticks and lashing are not included. Physical print, fit and use testing are pending; presets make no loom-fit claim. Measure the beam front to back, including any protective padding. Clearance is a total width allowance. The downward leg engagement must clear the loom on both sides. Flat-topped rectangular beams only, without projecting raddles or fittings. Measure the two flat sticks with their broad faces horizontal; both must share the same section. Seat the beam against the inside-facing saddle leg before lashing; width clearance lies at the opposite leg. The first center is measured from this beam contact face toward the shafts, with independent center spacing to the second stick. Square-bottom seats preserve the measured rectangular stick envelope and have 0.8 mm mouth chamfers. Leave the bracket width plus at least 4 mm exposed at each stick end outside the warp; keep yarn off printed surfaces. Lash each bracket over its cap and around the beam using soft cord or straps. Open notches do not lock sticks: keep the cross and sticks tied independently. For slack-stick support during threading only; remove before beaming, tensioning, weaving, folding or moving the loom. Clear burrs/stringing and protect the beam finish. Print both broad side profiles flat, 4 mm apart, PETG at 100% infill with a 0.4 mm nozzle and no supports. The complete pair must fit the 245 mm usable envelope within the Bambu A1's 256 mm bed. Checks preserve 4 mm webs and limit arm projection to 130 mm; this is a design boundary, not a load rating. Price follows exact solid material volume and surface area for both pieces. Physical print, fit, finish and use testing are pending. Test without a warp first. Presets are measured examples and make no brand-fit claim.
