Bathroom corner shelf — rock texture
Draining corner shelf with shallow faceted relief on its two outside walls. Match its size to the spacers and caps. One quantity supplies one shelf; rods and hardware are separate.
From $22.63Customizable

Loading 3D preview…
Free for personal use. Please don't sell prints.
Millimeters · flat on the print bed · separate parts in a ZIP.
Bambu A1 · Fits the 256 mm bed
Print the flat draining lattice down, retaining rim and rod collar up. Keep the supplied orientation. The 100% size has an 8.6 mm nominal production bore. The 8 mm rod preset uses 100%; the 10 mm rod preset uses 123.3%. Both give about 0.3 mm radial clearance. Polygon flats can slightly reduce the bore. Uniform scaling changes the bore, lengths and stock together. Use the same percentage for shelves, spacers and cap, and choose the actual rod for the scaled bore with about 0.4–0.8 mm total diametral allowance. Trial one spacer and cap on the rod first; do not force a tight fit. For the original layout, use three shelves, two spacers between adjacent shelves (four total), one top cap and the separate 8 × 300 mm rod. PETG only. Check support at both walls, drainage and gradual loading before use. Load and wet-use testing are pending. The store reserves an 11 mm bed margin.
Physical print testing is pending.
A draining corner shelf that stacks on a single rod.
A quarter-circle shelf with a 185 mm wall reach, raised lips, and drainage. For a three-tier organizer, order three shelves, four rod spacers, and one top cap, plus an 8 × 300 mm carbon-fiber rod (not included).

Draining corner shelf with shallow faceted relief on its two outside walls. Match its size to the spacers and caps. One quantity supplies one shelf; rods and hardware are separate.
From $22.63Customizable

A 62 mm spacer between corner-shelf tiers.
From $8.00Customizable
